UV Silicon Detector, 200-1100 nm, OD3 Attenuator
The Enhanced Silicon Photodetector, designed for low optical power measurements. It features include integrated calibration-data storage, built-in OD3 attenuation filter with automatic On/Off detection, temperature sensing electronics for temperature drift compensation and is compatible with DB15 based Newport Power Meters. The UV Enhanced Silicon (UV-Si) photodetector is NIST-traceable calibrated for 200-1100 nm optical power measurements. It includes a certificate of calibration with calibration curves and data for both attenuator on and off conditions.
Resources & Downloads
2D Product Drawings
918D CAD Drawing(96 kB, PDF)
Technical Notes
A Shortcut for Calculating Power Density(35.2 kB, PDF) Semiconductor Detector and Low Power Light Source(1.4 MB, PDF) Average and Peak Power Calculation(31.9 kB, PDF) Understanding Total Measurement Uncertainty
Manuals
918D Photodiode Sensors User Manual(4.3 MB, PDF)
Other
918D Series EU27 CE Declaration of Conformity(189.7 kB, PDF) 918D-UV-OD3R V2 RoHS Certificate(344.3 kB, PDF)
Literature
918D Photodiode Sensors Datasheet(1.8 MB, PDF)
