Adaptor Bracket, MT Series Stages
Adaptor Bracket, MT Series Stages
Model: MT-AB2
Product Series Overview
Compact Dovetail Linear StagesThe MT-AB2 Right Angle Bracket is a two piece right angle bracket which can be disassembled to provide two identical adaptor plates ideal for mounting a variety of components atop MT Series stages. For example, the MT-RS Optic Rotator can be directly mounted to one of the MT stages using just one of the disassembled MT-AB2 adaptor plates. This adaptor bracket can also be used to stack an MT-X atop an MT-XY to form the MT-XYZ positioner allowing the flexibility to configure left- or right-handed 3-axis micropositioners with either a high or low profile Z-axis platform position.
Resources & Downloads
2D Product Drawings
MT-AB-2-DWG-S(100 kB, PDF)
Other
MT-AB2 RoHS Certificate(278.8 kB, PDF) MT-AB2_RoHS2021.pdf(681.9 kB, PDF)
