Mirror Mount, Lab Standard, EdgeGrip, 1.0 in., 2 Knob Actuators
Mirror Mount, Lab Standard, EdgeGrip, 1.0 in., 2 Knob Actuators
Model: M1-1D
Product Series Overview
M Series Clear Edge Mirror MountsThe M1-1D Mirror Mount is designed to hold and position D-shaped mirrors. The EdgeGrip design allows it to hold standard 1 in. (25.4 mm) round mirrors as well as square mirrors up to 0.32 in. (8.1 mm) thick. Two precision 100-TPI adjustment screws are standard providing exceptionally smooth, high-resolution adjustment up to ±4°.
Resources & Downloads
2D Product Drawings
M1-1D-351(277.3 kB, PDF)
Other
M1-1D RoHS Certificate(278.6 kB, PDF) M1-1D_RoHS2021.pdf(681.9 kB, PDF)
