Brewster Angle Dispersing Prism, Ultrafast, LaK21, 25 mm, 370-2000 nm

Brewster Angle Dispersing Prisms for Ultrashort Pulses

The 10LK10 Ultrafast Laser Brewster Angle Dispersing Prism is a 25.0 mm Prism made with N-LaK21 or equivalent glass, and optimized for 370-2000 nm. These prisms are used intracavity to compensate for dispersion of fixed cavity optics, such as a Ti:Sapphire crystal, or external cavity to manipulate pulse characteristics.

Specifications

Technical Specs

Transmission
370–2000 nm
Size
25 x 25 x 25 mm
Material
N-LaK21 or equivalent
Apex Angle
63.00°
Antireflection Coating
Uncoated
Surface Quality
40-20 scratch-dig
Surface Flatness
≤λ/10 at 632.8 nm over the clear aperture

Clear Aperture
≥90% of face
Chamfers
0.5 mm face width
Chamfers Angle Tolerance
45° maximum
Cleaning
See How to Clean Optics

Transmission
370–2000 nm
Size
25 x 25 x 25 mm
Material
N-LaK21 or equivalent
Apex Angle
63.00°
Antireflection Coating
Uncoated
Surface Quality
40-20 scratch-dig
Surface Flatness
≤λ/10 at 632.8 nm over the clear aperture

Clear Aperture
≥90% of face
Chamfers
0.5 mm face width
Chamfers Angle Tolerance
45° maximum
Cleaning
See How to Clean Optics

Resources & Downloads

2D Product Drawings

ULTRAFA3-S(76.3 kB, PDF)

Other

10LK10 RoHS Certificate(706.7 kB, PDF)

Application Notes

Prism Compressor for Ultrashort Laser Pulses(4.2 MB, PDF)
