Compare Model Drawings, CAD & Specs Availability Price
7Z11057
919P-BNC Adapter, DB15 to BNC, For DVM or Scope Use
$154
7 Weeks
 7Z11057 919P-BNC Adapter, DB15 to BNC, For DVM or Scope Use
7 Weeks
 $154
818P-BNC
Adapter, DB15 to BNC, For DVM or Scope Use
$164
In Stock
 818P-BNC Adapter, DB15 to BNC, For DVM or Scope Use
In Stock
 $164
818P-DIN
Adaptor, DB15 to DIN, or 1835-C or 2835-C Power Meter Use
$198
In Stock
 818P-DIN Adaptor, DB15 to DIN, or 1835-C or 2835-C Power Meter Use
In Stock
 $198
919P-18FA
Fiber Adapter Mounting Ring, 919P Series with 18 mm Active Diameter
$126
Contact Us
 919P-18FA Fiber Adapter Mounting Ring, 919P Series with 18 mm Active Diameter
Contact Us
 $126
919P-26FA
Fiber Adapter Mounting Ring, 919P Series with 26 mm Active Diameter
$123
3 Weeks
 919P-26FA Fiber Adapter Mounting Ring, 919P Series with 26 mm Active Diameter
3 Weeks
 $123
919P-35FA
Fiber Adapter Mounting Ring, 919P Series with 35 mm Active Diameter
$182
5 Weeks
 919P-35FA Fiber Adapter Mounting Ring, 919P Series with 35 mm Active Diameter
5 Weeks
 $182
919P-50FA
Fiber Adapter Mounting Ring, 919P Series with 50 mm Active Diameter
$721
5 Weeks
 919P-50FA Fiber Adapter Mounting Ring, 919P Series with 50 mm Active Diameter
5 Weeks
 $721
919P-FC
Optical Fiber Adapter, FC/PC, 919P Series Thermopile Power Sensors
$192
6 Weeks
 919P-FC Optical Fiber Adapter, FC/PC, 919P Series Thermopile Power Sensors
6 Weeks
 $192
919P-SMA
Fiber Adaptor, SMA, 919P Series Thermopile Power Sensors
$119
3 Weeks
 919P-SMA Fiber Adaptor, SMA, 919P Series Thermopile Power Sensors
3 Weeks
 $119

Features

Flexible Fiber Adapters

Detector Model

Required Mounting Ring

919P-030-18

919P-18FA

919P-040-50

919P-50FA

919P-050-26, 919P-150-26

919P-26FA

919P-250-35

919P-35FA

919P-020-12, 919P-050-18H

Fiber adapters not mountable

The 919P-SMA and 919P-FC fiber adapter can be used with most of the detector models. Remove the snout for Models 919P-003-10 and 919P-010-16 and directly mount the fiber adapters on the thread. In order to accommodate various aperture sizes, we provide adapter rings as well as the fiber adapters. Refer to the table for the corresponding adapter ring for each detector model. Note that certain models do not accept a fiber adapter.

Cable Adapters

The 818P-BNC converts DB15 terminated optical detectors to BNC for connection to a digital voltmeter (DVM) or an oscilloscope. The 818P-DIN Adapter Cable converts DB15 terminated 919P series thermopile detectors to 8-pin DIN for connection to Newport Cal-Module based optical power meters.
