Optical Table Support Set, Rigid, 22 in., 8,000 lb. Load, Qty 4
Optical Table Support Set, Rigid, 22 in., 8,000 lb. Load, Qty 4
Model: RL-2000-422
Product Series Overview
RL Rigid Optical Table SupportsThe RL-2000-422 Non-Isolating LabLegs™ Set offers rigid support where vibration isolation is not required. The set includes (4) 22 inch rigid legs with a 8000 lb total capacity. Unlike cross member support systems, the freestanding design does not amplify low frequency floor vibrations. The height adjustable RL Series is an excellent choice for off table target pointing applications.
Specifications
- Load Capacity per Isolator2000 lb (907 kg)
- Isolator Height22 in. (558.8 mm)
- Number of Isolators4
- Tie Bar FlangeNo
- Height Adjustment+ 0.75/-0.40 in.
(+19/-10 mm) - Crated Weight220 lb
Resources & Downloads
3D Product Models
Manuals
RL SL Manual Rev. C(221.1 kB, PDF)
Other
RL-2000-422 RoHS Certificate(278.9 kB, PDF)
2D Product Drawings
RL Series Lablegs Drawing(101.7 kB, PDF)
