Manual Linear Stage, Crossed-Roller, 25.4 mm, M4, M6, No Baseplate
The 9067-COM-M Stainless Steel Commercial Stages is a 1.0 inch (25.4 mm) travel linear translation stage designed to fit directly into your system. This stage has a reduced profile by eliminating the mounting plates. 9067 series stages feature a generous pattern of twenty M4 and twenty one M6 threaded mounting holes. Actuators are not included. Please see specifications for recommended actuators.
Resources & Downloads
2D Product Drawings
9067-COMb-Drawing.pdf(131.3 kB, PDF) 9067-COM.pdf(101.2 kB, PDF)
