ezTrac Optical Rail, 1.5 in. Length

19 mm Surface Mount Optical Rails & Carriers

The 9032 e⋅z⋅Trac Rail mounts directly to our stages or other accessories and lets you quickly configure and reconfigure your stage setup. The rail's precision alignment holes guarantee orthogonality when you reconfigure the stages, and the dovetail design ensures that the stages won't suffer from stability problems. The 9032 has a 1.5 inch length and is metric compatible.

Specifications

Technical Specs

Type
Optical Rail
Rail Length
39.4 mm
Thread Type
1-4-20 (M6) C-Bore
Height
4.6 mm

Length
39.4 mm
Width
19.1 mm

Type
Optical Rail
Rail Length
39.4 mm
Thread Type
1-4-20 (M6) C-Bore
Height
4.6 mm

Length
39.4 mm
Width
19.1 mm

Resources & Downloads

3D Product Models

Download CAD Files

2D Product Drawings

9032a-Drawing(81.3 kB, PDF)
