Sorry, this product is no longer offered for sale. The recommended replacement product is LBP2-HR-IR3.

Laser Beam Profiler, 1440-1605 nm Silicon CCD, 1928 x 1448 Pixels

Model: LBP2-HR-IR2

Laser Beam Profiler, 1440-1605 nm Silicon CCD, 1928 x 1448 Pixels

Laser Beam Profiler, 1440-1605 nm Silicon CCD, 1928 x 1448 Pixels

Model: LBP2-HR-IR2

Technical Specs

  • Detector Type
    Si CCD with phosphor coating
  • Spectral Range
    1440-1605 nm
  • Sensor Size
    7.1 x 5.3 mm
  • Pixel Spacing
    3.69 x 3.69 µm
  • Minimum Power Density
    50 µW/cm2
  • Minimum Spot Size
    600 µm
  • Damage Threshold
    50 W/cm2 , 0.1 J/cm2 with all filters installed for < 100 ns pulse
  • Computer Interface
    USB3
  • Operating Mode
    CW and Pulsed, Interline transfer progressive scan CCD
  • Shutter
    30 µs to multiple frame times
  • Gain
    0 dB to 24 dB
  • Dynamic Range
    30 dB
  • Number of Pixels
    1928 x 1448
  • Saturation Intensity
    7 mW/cm2 @ 1550 nm
  • Beam Size Accuracy
    ±2 %
  • Dimensions
    48 x 44 x 20.2 mm
  • CE
    Compliant
  • RoHS
    Compliant
  • Display Refresh Rate
    13 fps at full resolution (12 bit mode)
